Пруток из углеродистой стали A36

Пруток из углеродистой стали A36

A36 is a low-carbon steel that contains trace amounts of manganese, phosphorus, sulfur, silicon, copper and other elements. A36 has excellent welding performance and high yield strength, and is the most specified structural steel plate by engineers. ASTM A36 is most often manufactured into various structural steel parts. This grade is used for welded, bolted or riveted structures in bridges and buildings, as well as for general structural purposes. Due to its minimum yield point, A36 can be used to design lighter structures and equipment and provides good weld ability.

Product Parameter

A36 carbon steel bar
Standard EN/DIN/JIS/ASTM/BS/ASME/AISI
Common specifications of round bars 3.0-50.8 mm,Over 50.8-300mm
Common specifications of flat bars 6.35×12.7mm,6.35×25.4mm,12.7×25.4mm
Common specifications of hexagonal rods AF5.8mm-17mm
Common specifications of square rods AF2mm-14mm,AF6.35mm,9.5mm,12.7mm,15.98mm,19.0mm,25.4mm
Length 1-6meters,Can be customized according to customer requirements
Diameter

(mm)

Hot-rolled round bars



25-600 Cold-rolled square bars



6-50.8
Hot-rolled square bars



21-54 Cold-rolled hexagonal bars



9.5-65
Cold-rolled round bars 6-101.6 Forged reinforcing bars 200-1000
Surface technics Bright, polished, black
Other services Machining (CNC), centerless grinding (CG), heat treatment, annealing, pickling, polishing, rolling, forging, cutting, bending, small-scale processing, etc.

Chemical component

C Cu Fe Mn P Si S
0.25~0.290 0.20 98.0 1.03 0.040 0.280 0.050

Mechanical property

A36 Ultimate tensile strength Tensile strength, yield strength Elongation at break (unit:  )200mm) Elongation at break (unit50mm) Elasticity modulus



Modulus of volume (typical value for steel) Poisson’s ratio shear modulus
Metric system 400~550MPa 250MPa 20.0% 23.0% 200GPa 140GPa 0.260 79.3GPa
Imperial system 58000~79800psi 36300psi 20.0% 23.0% 29000ksi 20300ksi 0.260 11500ksi
